Connection 1

Connection technology CAGE CLAMP®

Actuation type Operating tool

Connectable conductor materials Copper

Nominal cross-section 4 mm²

Solid conductor 0.08 … 4 mm² / 28 … 12 AWG

More

Physical data

Pin spacing 5 mm / 0.197 inch

Width 75.4 mm / 2.969 inch

Height from the surface 18.3 mm / 0.72 inch

Depth 40.2 mm / 1.583 inch

Mechanical data

Variable coding Ja

Mounting type Mounting flange

Plug-in connection

Contact type (pluggable connector) Male connector/plug

Connector (connection type) for conductor
