Details

Electrical data

Ratings per IEC/EN

Ratings per IEC/EN 60947-7-2

Connection data

Total number of connection points 4

Total number of potentials 1

Number of levels 1

Connection 1

Connection technology CAGE CLAMP®

Actuation type Operating tool

Connectable conductor materials Copper

Solid conductor 0.08 … 1.5 mm² / 28 … 16 AWG

Fine-stranded conductor 0.08 … 1.5 mm² / 28 … 16 AWG

More

Physical data

Width 4 mm / 0.157 inch

Height 73 mm / 2.874 inch

Depth from upper edge of DIN-rail 27 mm / 1.063 inch

Mechanical data

Design horizontal type

Mounting type DIN-35 rail

Marking level Center marking

Material data

Color green-yellow

Insulation material Polyamide (PA66)

Flammability class per UL94 V0

Fire load 0.104MJ

Weight 9.9g

Commercial data

Product Group 1 (Rail Mounted Terminal Blocks)

PU (SPU) 100 Stück

Packaging type box

Country of origin DE

GTIN 4045454084455
