Electrical data
Ratings per IEC/EN
Ratings (note) Electrical ratings are given by the fuse.
Nominal voltage (III/3) 250V
Rated current 6.3A
Operation status indicator none
Power loss
Power loss (max.) Pl (max.) (note) When selecting glass cartridge fuses, make sure that the maximum power loss listed below is not exceeded. The power loss is determined according to IEC or EN 60947-7-3/VDE 0611-6 at 23°C. The temperature rise of the terminal block must be checked according to their application and mounting. Higher ambient temperatures represent an additional impact on miniature fuses. Therefore, in such applications, the rated current must be reduced if necessary. More details are available from the manufacturers.
General
Fuse type Rundsicherung; 5 x 20 mm und 5 x 25 mm
Physical data
Width 6 mm / 0.236 inches
Mechanical data
Marking level Center marking
