The West 8100+ is part of the Plus Series of controllers that take flexibility and ease of use to new levels.

The 8100+ controller is an evolved product from the N8100. The product benefits from having more versatile features and user-friendly functionalities such as  remote setpoint inputs, digital inputs, plug-in output modules, a customisable operator/HMI menu, jumperless and auto-hardware configuration, and 24VDC transmitter power supply.

It has been designed to incorporate improvements, save users’ time (as much as 50% on product set-up), reduce inventory stock and virtually eliminate the likelihood of operator errors.

Manufacturer West Control Solutions

Series West 8100+

Din Size 1/8

Dimensions and Size 96mm x 48mm x 100mm (HxWxD), 1/8 DIN

Primary Input Type Universal (TC, RTD, DC linear mA/mV)

Other Inputs Digital, Remote setpoint

Output Type Relay, SSd, DC linear V or mA, Triac, 24V transmitter power supply

Max. Number of Outputs    3

Control Type PID, ON/OFF, Manual, Alarm, Ramp to Setpoint

Power Supply 100–240V AC 50–60Hz

20-48V AC 50/60 Hz  22-65V DC

Communications RS-485 serial (West ASCII or MODBUS®)

Panel Sealing IEC IP66 (Behind panel protection is IP20), NEMA4X

Certifications CE, UL, ULC, CSA

Software Tools Plus Series Configurator
