Notes
Safety information 1 Max. insulation diameter: 4.4 mm
Safety information 2 2-conductor female plugs cannot be used.
Connection data
Total number of connection points 2
Total number of potentials 1
Number of levels 2
Connection 1
Connection technology CAGE CLAMP®
Actuation type Operating tool
Connectable conductor materials Copper
Solid conductor 0.08 … 2.5 mm² / 28 … 12 AWG
Fine-stranded conductor 0.08 … 4 mm² / 28 … 12 AWG
Fine-stranded conductor; with insulated ferrule 0.08 … 1.5 mm² / 28 … 14 AWG
Strip length 6 … 7 mm / 0.24 … 0.28 inches
Wiring direction Front-entry wiring
